Xantrex 1000 Watt 12V Power Inverter with 20A Charger 806-1020

Continuous power1,000 W
Nominal voltage12 V

$489.00

Out of stock

This item cannot be ordered online right now. Call (727) 761-7772 to ask about availability.

Compare

Works with: 12 V systems

Questions? Call (727) 761-7772

SKU 806-1020

Pairs well with

AIMS Power AGM 12V 200Ah Deep Cycle Battery Heavy Duty$384.13Details of AIMS Power AGM 12V 200Ah Deep Cycle Battery Heavy Duty
Battle Born 100Ah 12V GC2 LiFePO4 Battery$749.00Details of Battle Born 100Ah 12V GC2 LiFePO4 Battery
Battle Born 100Ah 12V LiFePO4 Lithium Deep Cycle Battery$749.00Details of Battle Born 100Ah 12V LiFePO4 Lithium Deep Cycle Battery

Nothing selected

Overview

Xantrex Freedom 806-1020 Video:

No Messy Wiring. Quick Installation. Minimal Battery Drain. The new generation Freedom HF is equipped with quick-connect AC terminals and ignition lockout capability. The quick-connect AC terminals enable quick installation eliminating the need for strain relief clamps. The ignition lockout feature helps to minimize battery drain by disabling the inverter when the ignition is turned off.

The Freedom HF Inverter/Charger is one of the smallest, lightest, and most affordable inverter/chargers in the market today. The Freedom HF Inverter/Charger features modified sine wave output and is designed to operate entertainment systems and small appliances in boats, RVs and trucks. The Freedom HF is available in three models: 1000 watts with a 20-amp charger, 1000 watts with a 55-amp charger and 1800 watts with a 40-amp charger.

Some of the key feature enhancements include quick-connect AC terminal block on both AC input and output for incredibly easy installation. The ignition lockout feature minimizes battery drain by disabling the inverter when the ignition is turned off.

Xantrex Part Number: 806-1020

Features:

Show the full description

Removable digital display pre-attached with 25 extension cable for remote system monitoring
Ignition lockout feature helps to minimize battery drain
Automatic three-stage battery charger
Designed to be hardwired using quick-connect AC terminal blocks or by connecting AC through GFCI receptacles (included)
Built-in 30-amp relay to automatically transfer between inverter power and incoming AC utility power

Protection Features:

Battery over-voltage and under-voltage protection
Over-temperature shutdown
Automatic overload protection
Short-circuit protection
Ground-fault protection
ETL certified to UL458 for use in mobile RV and commercial applications

Inverter Specifications:

Output power (continuous): 1000 watts
Surge power: 2000 watts
Output frequency regulation: 60 Hz
Inverter voltage regulation: 115 V +/-10 Vrms
Output wave form: Modified Sine Wave
Efficiency (full load): 80%
Peak efficiency: 87%
No load input power: < 10 W
Off mode current draw (display off): < 1 mA

Charger Specifications:

Charge rate: 20A
AC Input voltage range: 90 – 130 VAC
AC transfer relay: 30A
Battery voltage (nominal): 12 VDC
Operating voltage range: 10.5 – 15.5 VDC
Low battery cut-out: 10.5 VDC
AC Input (max. charge): 5A AC
Default bulk charge voltage setting: 14.2 VDC
Default float charge voltage setting: 13.5 VDC
Battery charge outputs: One
Charge control: Three-stage
Battery type settings: Flooded / Gel / AGM/ Fixed 13.5 VDC
Equalization: No
Internal temperature-sensitive charging: Yes

General Specifications:

Optimal operating temperature range: 32°F – 104°F
Optional remotes: Detachable Display
Dimensions (H x W x L): 4.2″ x 9.5″ x 15.5
Weight: 10 lb (4.5 kg)
Warranty: Two years

Regulatory & Environmental Compliance:

ETL Certified to CSA Standard C22.2 No. 107.1, UL458 with marine supplement (drip shield, part # 808-9531).

Specifications

Key specifications
Continuous power	1,000 W
Battery voltage	12 V
Output	Not listed
Max PV input	Not listed
MPPT trackers	Not listed
Warranty	2 Year
Certifications	UL 458
Dimensions	Not listed
Weight	10 lb
